Vehicle Inverter Products
1. Wide Applicability Across Multiple Fields
Our product demonstrates excellent adaptability and reliability in a wide range of applications, including transportation systems, railway engineering, industrial automation control, communication and switching equipment, civil office facilities, agricultural and industrial production, military and medical devices, logistics, and transportation.
2. Outstanding Technical Advantages
Thanks to its superior output waveform and minimal distortion, our solution delivers clean and stable power support. It also generates minimal interference to surrounding equipment and operates with low noise, effectively ensuring a stable and quiet working environment.
| Type | Pure Sine Wave Inverter |
| Peak Power | 3000W | 4000W | 5000W | 6000W | 8000W | 11000W |
| Rated Power | 1500W | 2000W | 2300W | 3000W | 4000W | 5000W |
| Input Voltage | 12V & 24V |
| Product Output | 110VAC & 220VAC & USB 5V & TYPE-C 5V |
| Display | Digital Display |
| Output Frequency | 50HZ±1%/60HZHZ±1% |
| Output Waveform | Pure Sine Wave |
| Distorton Rate | THD<3%(Inductive Load) |
| Efficiency | 90% |
| Input Voltage | 12V(10-16V) |
| 24V(20-32V) |
| Overload Protectiong | 120%-125% |
| Protection Function | Low voltage: LED light red, buzzer alarm, automatic recovery |
| High voltage: LED light red, buzzer alarm, automatic recovery |
| Overload: LED light red, buzzer alarm, automatic power off, need to restart |
| High temperature: LED light red, buzzer alarm, automatic recovery |
| Short circuit(less than 2 seconds); automatic recovery |
| Input reverse connection; the fuse is blown |
| Operating Temperature | -10℃-40℃ |
| Storage Temperature | -20℃-85℃ |
| Operating Height | ≤3000m |
| Product Size(mm) | 306*150*71.5 | 348*152*70.6 | 385*152*70.6 | 376*219*94 | | 475*219*150 |
| Weight | 1.73kg | 2.08kg | 2.44kg | 4.94kg | | 8.6kg |
Product Single Package Size
(mm) | 350*215*140 | 395*215*140 | 435*215*140 | 435*320*190 | | 538*283*228 |
| Product G.W. | 2.4kg | 2.8kg | 3.2kg | 6kg | | 9.6kg |
